Building on proven CAD/CAM expertise, Eckelmann addresses demanding CAD/CAM challenges directly at the machine with two complementary software solutions: the established cncCUT and the advanced E°CAM application.
With cncCUT, Eckelmann developed a complete CAD/CAM package featuring a unique operating concept and extensive functionality. E°CAM takes things further as a user-friendly, future-oriented plug-and-play solution with built-in nesting features. Its intuitive HMI optimizes material utilization, making nesting functionalities a key contributor to sustainable production efficiency and long-term cost reduction.
From flexible contract manufacturing to fully automated production processes, Eckelmann provides comprehensive, user-friendly cutting solutions from a single source. These solutions combine versatile modules and interfaces tailored to individual automation requirements – manufacturer-independent and open for downstream processes or upgrades.
The proven cncCUT package offers cutting and punching in a single solution, including programming for combination machines.
E°CAM covers the entire process chain: from drawing functions, predefined macros, and DXF import, to nesting algorithms and machine code generation. In addition to part geometry, it also considers typical material properties, dimensions, and shapes.
Key benefits of Eckelmann CAD/CAM products:
-
Significant time savings in order processing and setup
-
Sheet and remnant plate management
-
Manage and nest production orders
-
Optimal plate utilization through advanced nesting algorithms
-
Combine multiple jobs from different customers
-
Database connectivity to MS-SQL Server / integration of various technology modules
-
Custom interfaces to ERP/MES systems / cross-network operation
With cncCUT, Eckelmann provides a complete CAD/CAM package with a unique operating concept and extensive functionality:
- Cutting and punching in one package
- Includes programming for combination machines
- Significant time savings in order processing and setup
- Sheet and remnant plate management
- Manage production orders
- Optimal plate utilization through nesting algorithms
- Combine different orders from multiple customers
- Database connectivity to MS-SQL Server / integration of various technology modules
E°CAM offers a complete CAD/CAM software solution for oxy-fuel, plasma, laser, and waterjet machines:
- Intuitive, user-friendly interface
- Programming possible both at the machine and at the desktop
- Fully integrable with Eckelmann’s E°CUT cutting solution on request
- Innovative 3D part creation within seconds
- Optimized, future-ready geometry processing
- 3D visualization in the CAD module
- Drawing functions / predefined macros
- Nesting algorithm
- DXF/DWG import with 3D visualization simplifies drilling and bevel cutting
