Hardware & Electrical Design Your Partner for Hardware & Software

Specific Electronic Development

This is where Eckelmann’s standard controllers are created, such as refrigeration controllers, composite controllers, the EXC89/88, and more.

• PCB design with standard planning tools
• Boards/modules up to 14 layers
• SMD and THT solutions (also combined)
• Development according to the standards and guidelines of the respective industry
• Interface to the ERP system (BOM, production planning)
• ICT test / automated testing

Specific Electronics for Embedded Solutions

• Modules specifically developed to customer requirements
• Based on self-developed platforms or as completely new development, from prototype to series production.
• Standard or regulated environment according to applicable standards and guidelines
• With our own VHDL development (FPGA), for example, for real-time applications

Control Cabinets: Custom Solutions & Series Production

Control cabinets at Eckelmann are developed, planned, and then manufactured using standard planning tools like E-Plan.

The construction of the control systems is then carried out using market-standard components in accordance with our customers’ specifications.

In addition to custom solutions, Eckelmann increasingly handles series production. We are familiar with the development of prototypes through A-samples, B-samples, and up to pilot series.

Of course, Eckelmann is familiar with and complies with the relevant standards and guidelines depending on the industry.

Eckelmann’s design competencies extend to the smallest corners of electrical engineering.
